QuickSpecs
HP Compaq dx2480 Microtower Business PC
System Details
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 7
Memory Type
PC2-6400 DDR2 SDRAM (800MHz) non-ECC
Up to 8-GB maximum system memory supported
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system,
all memory may not be available due to system resource requirements. Addressing memory above
4 GB requires a 64-bit operating system.
Technology and
Features
Hard Drive
Interfaces
Supported
Serial ATA
Front Panel
Power button
Power On LED
HDD Activity LED
Cooling Solutions
Supported
Power Supply Fan (variable speed)
Active heatsink (variable speed)
Chassis fan (variable speed)
Slots Supported
Four (4) full-height expansion slots
Front I/O
Two (2) USB 2.0 ports
Rear I/O
Standard Micro ATX I/O connectors, including Six (6) USB 2.0 ports
Drive Bays
Two (2) 5-1/4” external
Two (2) 3-1/2” external
Two (2) 3-1/2” internal
Internal Speaker
Optional
Security
Chassis Intrusion switch
Kensington Lock Support (Optional)
Chassis
Power Supply
300-watt ATX Power Supply – non-PFC with a 230v
General Unit Operating Guidelines
• Keep the computer away from excessive moisture, direct moisture and the extremes of
heat and cold, to ensure that unit is operated within the specified operating range.
• Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the
required airflow.
• Never restrict airflow into the computer by blocking any vents or air intakes.
• Do not stack computers on top of each other or place computers so near each other that
they are subject to each other's re-circulated or preheated air.
• Occasionally clean the air vents on the front, back, and any other vented side of the
computer. Lint, dust and other foreign matter can block the vents and limit the airflow.
• If the computer is to be operated within a separate enclosure, intake and exhaust
ventilation must be provided on the enclosure, and the same operating guidelines listed
above will still apply.
Operating
32° to 113° F (0° to 45° C)
Unit Environment
and Operating
Conditions
Temperature Range
Non-operating
-22° to 140° F( -30° to 60° C)
