QuickSpecs
HP Compaq dx2480 Microtower Business PC
System Details
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 9
Board Size
Micro-ATX, PCB Size: 9.6’’ x 9.6’’ in (24.38 x 24.38 cm)
4-layer PCB with green color
Additional Features
• Bootable without keyboard, mouse or monitor
• Keyboard/mouse/USB wake up
• Support S3, S4 and S5
• ACPI status
• Hardware monitor capability
• CPU fan speed control
Hardware
Highlights
Integrated Realtek 8111C- GbE
Ethernet Controller
Features
Hardware
Highlights
PCI Express interface
Network
Interface
Intel PRO/1000 PT Gigabit PCIe
Adapter
Features
10-Mbps, 100-Mbps and 1000-Mbps
operation
Power Supply
• ATX Power Supply – Non-PFC with 230v
• 50–60 Hz rated line frequency
• 300 watt maximum rated power
• 80-mm power supply fan – variable speed for optimum acoustics
Power Conservation
‘Energy Saver‘
• APM 1.2 support
• Screen blanking
• System Idle mode
• Values are subject to change without notification and are for reference only.
• Performance of system, options, and ancillary equipment will vary depending on the
system configuration.
• Levels presented do not account for non-HP/Compaq installed hardware.
Operating
32° to 113°F (0° to 45°C) at sea level with
an altitude de-rating of 1.0°C per every
1000 ft (300 m) above sea level to a
maximum of 8000 ft (2500 m), no direct
sustained sunlight. Maximum rate of change
is 77°F/Hr (25°C/Hr). The upper limit may
be limited by the type and number of options
installed.
System
Environmental Specs
Ambient Air
Temperature
Storage
