EL-MF877-00 Page 10
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure 25 Loose the screws on the HDD cage
Figure 26 Push the handle of the HDD cage
Figure 27 Pull the HDD cage off the chassis
Figure 28 Loose the screws on the side of HDD cage
Figure 29 Loose the screws on other side of HDD
cage
Figure 30 Pull the HDD from the HDD cage
