Removing or replacing the service door
CAUTION: To prevent information loss or an unresponsive system:
Save your work and shut down the computer before adding or replacing a memory module or hard
drive.
If you are not sure whether the computer is off or in Hibernation, turn the computer on by sliding the
power switch. Then shut down the computer through the operating system.
Removing the service door
Remove the service door to access the memory module slots, hard drive, and other components.
To remove the service door:
1. Remove the battery (see
Inserting or removing the battery on page 26).
2. Loosen the 2 screws (1).
3. Slide the service door toward the front of the computer (2), and then lift the service door (3) to
remove it.
Replacing the service door
Replace the service door after accessing the memory module slots, hard drive, and other
components.
28 Chapter 5 Maintenance
