HP EliteBook 2540P Specifications

Keyboard
KeyboardKeyboard
Keyboard The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a
drain system that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of
damage to sensitive components underneath. The 101/102-key compatible keyboard features an
industry standard, full-pitch key layout with desktop keyboard features, such as the isolated inverted-T
cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys. U.S. and
International key layouts are available. Other features include an integrated numeric keypad, hotkeys for
instant access to power conservation, brightness, and other features, 19 mm x 19 mm key pitch (center-
to-center spacing), 2.0 mm stroke, and comfort-dished keycaps.
HP DuraKeys is a clear coating applied over the notebook keyboard that helps protect the finish and the
printed characters on the keys. HP DuraFinish helps protect the finish on the keyboard deck, graphics,
and icons from normal wear and tear.
HP Night Light shines directly on keyboard for low-light conditions.
Touch-sensitive controls
Touch-sensitive controlsTouch-sensitive controls
Touch-sensitive controls Touch-sensitive controls provide easy access to the following features: HP QuickLook 3, HP QuickWeb,
wireless on/off, touchpad on/off, volume mute, volume down, volume up.
Dual Pointing devices
Dual Pointing devicesDual Pointing devices
Dual Pointing devices Touchpad with scroll zone, two pick buttons
Pointstick, two additional pick buttons
Expansion card slots
Expansion card slotsExpansion card slots
Expansion card slots ExpressCard/34 slot
ExpressCard/34 slotExpressCard/34 slot
ExpressCard/34 slot Supports ExpressCard/34
Integrated Smart Card
Integrated Smart CardIntegrated Smart Card
Integrated Smart Card
Reader
ReaderReader
Reader
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
Secure Digital slot
Secure Digital slotSecure Digital slot
Secure Digital slot Supports SD (Secure Digital), MMC (MultiMedia Card)
Internal Storage
Internal StorageInternal Storage
Internal Storage Standard Voltage Processor Configurations
Standard Voltage Processor ConfigurationsStandard Voltage Processor Configurations
Standard Voltage Processor Configurations
2.5-inch storage bay
2.5-inch storage bay2.5-inch storage bay
2.5-inch storage bay 2.5-inch 250/320/500 GB 7200 rpm SMART SATA II Hard Drive
-or-
2.5-inch 80/160 GB Solid State Drive
NOTE:
NOTE:NOTE:
NOTE: 1.8-inch hard drive bay is not available with a standard voltage processor.
Low Voltage Processor Configurations
Low Voltage Processor ConfigurationsLow Voltage Processor Configurations
Low Voltage Processor Configurations
1.8-inch hard drive bay
1.8-inch hard drive bay1.8-inch hard drive bay
1.8-inch hard drive bay 1.8-inch 160/250/320 GB 5400 rpm SMART SATA II Hard Drive
-or-
1.8-inch 80/160 GB Solid State Drive
2.5-inch secondary hard
2.5-inch secondary hard2.5-inch secondary hard
2.5-inch secondary hard
drive for RAID support
drive for RAID supportdrive for RAID support
drive for RAID support *
2.5-inch 250 GB 7200 rpm SMART SATA II Hard Drive
* Requires1.8-inch 250 GB 5400 rpm hard drive in 1.8” hard drive bay.
NOTE:
NOTE:NOTE:
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles.
Up to 15 GB is reserved for the system recovery software.
QuickSpecs
HP EliteBook 2540p Notebook PC
HP EliteBook 2540p Notebook PCHP EliteBook 2540p Notebook PC
HP EliteBook 2540p Notebook PC
Standard Features (availability may vary by country)
DA - 13566 North America — Version 8 — June 2, 2010 Page 8

HP EliteBook 2540P Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-640LM
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-600 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	25 W
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QM57 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Display diagonal	12.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Discrete graphics card model	-
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	266 MHz
On-board graphics card dynamic frequency (max)	566 MHz
Type	PC
Intel segment tagging	Enterprise
Bluetooth version	2.1+EDR
Operating system installed	Windows XP Professional
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
Cable lock slot type	Kensington
Product color	Black
Country of origin	China
Pointing device	Touchpad
Processor code	SLBMK
Processor ARK ID	43563
Processor package size	BGA 34 x 28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1, SSE4.2
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	210 mm
Width	280 mm
Weight	1530 g
Height (front)	30 mm
