HP EliteBook 2540P Specifications

HP 3D DriveGuard
HP 3D DriveGuardHP 3D DriveGuard
HP 3D DriveGuard
(Windows models with
hard drives only)
The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer temporarily
halts all data transfer and parks the hard drive when abrupt motion is
detected.
Fixed Optical Bay
Fixed Optical BayFixed Optical Bay
Fixed Optical Bay
(low voltage processor
configurations only)
9.5 mm SATA optical
9.5 mm SATA optical9.5 mm SATA optical
9.5 mm SATA optical
drive
drivedrive
drive
DVD+/-RW SuperMulti DL Drive
DVD-ROM Drive
-or-
Secondary hard drive
Secondary hard driveSecondary hard drive
Secondary hard drive * 2.5-inch 250 GB 7200 rpm SMART SATA II Hard Drive for RAID support
-or-
Weight Saver
Weight SaverWeight Saver
Weight Saver
* Requires1.8-inch 250 GB 5400 rpm hard drive in 1.8-inch hard drive bay.
External Optical Drive
External Optical DriveExternal Optical Drive
External Optical Drive Optional HP External USB CD/DVD R/RW Drive
Interfaces
InterfacesInterfaces
Interfaces ExpressCard/34 slot
ExpressCard/34 slotExpressCard/34 slot
ExpressCard/34 slot One
Smart Card Reader
Smart Card ReaderSmart Card Reader
Smart Card Reader One
External monitor
External monitorExternal monitor
External monitor Two – (1) DisplayPort, (1) VGA
Secure Digital slot
Secure Digital slotSecure Digital slot
Secure Digital slot One
1394a
1394a1394a
1394a One
Combo
ComboCombo
Combo
headphone/microphone
headphone/microphoneheadphone/microphone
headphone/microphone
jack
jackjack
jack
One
Power connector
Power connectorPower connector
Power connector One
RJ-11/modem
RJ-11/modemRJ-11/modem
RJ-11/modem One
RJ-45/Ethernet
RJ-45/EthernetRJ-45/Ethernet
RJ-45/Ethernet One
USB 2.0
USB 2.0USB 2.0
USB 2.0 Three (including one powered)
Fourth USB 2.0 port available on configurations with 2.5-inch hard drive
Docking connector
Docking connectorDocking connector
Docking connector For HP 2540 Docking Station
QuickSpecs
HP EliteBook 2540p Notebook PC
HP EliteBook 2540p Notebook PCHP EliteBook 2540p Notebook PC
HP EliteBook 2540p Notebook PC
Standard Features (availability may vary by country)
DA - 13566 North America — Version 8 — June 2, 2010 Page 9

HP EliteBook 2540P Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-640LM
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-600 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	25 W
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QM57 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Display diagonal	12.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Discrete graphics card model	-
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	266 MHz
On-board graphics card dynamic frequency (max)	566 MHz
Type	PC
Intel segment tagging	Enterprise
Bluetooth version	2.1+EDR
Operating system installed	Windows XP Professional
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
Cable lock slot type	Kensington
Product color	Black
Country of origin	China
Pointing device	Touchpad
Processor code	SLBMK
Processor ARK ID	43563
Processor package size	BGA 34 x 28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1, SSE4.2
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	210 mm
Width	280 mm
Weight	1530 g
Height (front)	30 mm
