Using system restore points
When you back up your system, you are creating a system restore point. A system restore point allows
you to save and name a snapshot of your hard drive at a specific point in time. You can then recover
back to that point if you want to reverse subsequent changes made to your system.
NOTE: Recovering to an earlier restore point does not affect data files saved or e-mails created since
the last restore point.
You also can create additional restore points to provide increased protection for your system files and
settings.
When to create restore points
Before you add or extensively modify software or hardware
Periodically, whenever the system is performing optimally
NOTE: If you revert to a restore point and then change your mind, you can reverse the restoration.
Create a system restore point
1. Select Start > Control Panel > System and Security > System.
2. In the left pane, click System Protection.
3. Click the System Protection tab.
4. Under Protection Settings, select the disk for which you want to create a restore point.
5. Click Create.
6. Follow the on-screen instructions.
Restore to a previous date and time
To revert to a restore point (created at a previous date and time), when the computer was functioning
optimally, follow these steps:
1. Select Start > Control Panel > System and Security > System.
2. In the left pane, click System protection.
3. Click the System Protection tab.
4. Click System Restore.
5. Follow the on-screen instructions.
108 Chapter 12 Backup and recovery

Table of Contents

Other manuals for HP EliteBook 2560p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 2560p and is the answer not in the manual?

HP EliteBook 2560p Specifications

General IconGeneral
Bus typeDMI
SteppingJ1
Tjunction100 C °C
Processor cache4 MB
Processor cores2
Processor modeli7-2640M
System bus rate5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-2600 Mobile Series
Processor socket-
Processor threads4
Processor codenameSandy Bridge
Processor frequency2.8 GHz
Processor cache typeSmart Cache
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency3.5 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)28
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® QM67 Express
HDD speed7200 RPM
HDD interfaceSATA II
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity320 GB
Compatible memory cardsMMC, SD
Number of HDDs installed1
Display diagonal12.5 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1333 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory16 GB
TypePC
Intel segment taggingEnterprise
On-board graphics card ID0x116
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 3000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1300 MHz
Audio systemSRS PS
Pointing deviceTouchpad + Pointing Stick
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version2.1+EDR
Cabling technology10/100/1000Base-T(X)
Top Wi-Fi standardWi-Fi 4 (802.11n)
Networking featuresGigabit Ethernet
Ethernet LAN data rates10, 100, 1000 Mbit/s
Trial softwareNorton Internet Security 2011
Operating system installedWindows 7 Professional
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports0
Battery capacity55 Wh
Battery life (max)8.5 h
Number of battery cells6
AC adapter power65 W
Operating temperature (T-T)5 - 35 °C
Sustainability certificatesENERGY STAR
Processor codeSR03R
Processor ARK ID53464
Processor package size37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Country of originChina
Weight and Dimensions IconWeight and Dimensions
Depth209 mm
Width305.2 mm
Height27.4 mm
Weight1670 g
