8.
VGA connector (external monitor/projector)
16.
Bluetooth module compartment
Bottom View
1.
Docking connector
5.
WWAN module compartment
2.
Secondary battery connector
6.
Battery release latch
3.
Memory module compartment
7.
SIM slot for WWAN (select models) – inside battery bay
4.
Hard drive bay
8.
Battery bay
NOTE:
WLAN module connector is located under the keyboard (not shown)
QuickSpecs
HP EliteBook 6930p Notebook PC
Overview
DA - 13061 North America — Version 22 — March 29, 2010
Page 3
