1. Memory module and WLAN compartment 5. Battery bay
2. Hard drive bay 6. Battery release latch
3. Business card holder 7. Docking connector
4. Secondary battery connector
NOTE: WWAN module compartment is accessible under the keyboard.
At A Glance
Genuine Windows Vista Business 32, Genuine Windows Vista Business 64, Genuine Windows Vista Ultimate 32, Genuine Windows
Vista Business with downgrade to Windows XP Professional custom installed, or FreeDOS
NVIDIA Quadro FX 770M graphics with up to 512 MB dedicated memory, or ATI Mobility FireGL V5700 graphics with up to 256 MB
dedicated memory
DirectX 10 support and Dual Link DVI (available through optional docking) provides faster rendering capabilities and support for
ultra-high resolution monitors
Intel® Centrino® 2 with vPro™ technology capable, with Intel Core™2 Extreme or Intel Core™2 Duo processors
Designed to travel, with weight starting at 6.3 lb/2.86 kg and 1.1-inch/28.2 mm thin at front
Business Rugged – designed to meet the military standard Mil-Std-810F for shock, vibration, sand and dust, humidity, altitude,
and high temperature operation *
HP Performance Tuning Framework for optimal configuration, compatibility and performance
Flexible wireless connectivity options:
Integrated HP un2400 EV-DO/HSDPA Mobile Broadband Module provides worldwide Gobi mobile Internet technology
Integrated 802.11 a/b/g/draft-n wireless LAN module
Bluetooth®
QuickSpecs
HP EliteBook 8530w Mobile Workstation
Overview
DA - 13093 North America — Version 12 — September 18, 2009 Page 3

HP EliteBook 8530w Specifications

Processor

Processor 1	Intel Core 2 Extreme Processor QX9300 (2.53 GHz, 12 MB L2 cache, 1066 MHz FSB)
Processor 2	Intel Core 2 Extreme Processor X9100 (3.06 GHz, 6 MB L2 cache, 1066 MHz FSB)
Processor 3	Intel Core 2 Quad Processor Q9100 (2.26 GHz, 12 MB L2 cache, 1066 MHz FSB)
Processor 4	Intel Core 2 Duo Processor T9600 (2.80 GHz, 6 MB L2 cache, 1066 MHz FSB)
Processor 5	Intel Core 2 Duo Processor T9400 (2.53 GHz, 6 MB L2 cache, 1066 MHz FSB)
Processor 6	Intel Core 2 Duo Processor P8600 (2.40 GHz, 3 MB L2 cache, 1066 MHz FSB)
Processor 7	Intel Core 2 Duo Processor P8400 (2.26 GHz, 3 MB L2 cache, 1066 MHz FSB)

Memory

Memory Type	DDR2 SDRAM, 800MHz
Memory Capacity per Slot	1024/2048/4096 MB SODIMMs
Maximum Memory Capacity	up to 8192MB total

Storage

Internal Storage 1	120/160/250 GB 5400rpm SATA HDD
Internal Storage 2	160/250/320 GB 7200rpm SATA HDD
Solid State Drive	80 GB

Display

Display 1	15.4-inch diagonal WXGA Anti-Glare (1280 x 800)
Display 2	15.4-inch diagonal WXGA+ Anti-Glare (1680 x 1050)
Display 3	15.4-inch diagonal WUXGA+ Anti-Glare (1920 x 1200)

Power

Battery 1	8-cell (73 WHr) Lithium-Ion battery
Optional Battery 1	HP (52 WHr) Extended Life Battery
Optional Battery 2	HP (95 WHr) Ultra-Capacity Battery
AC Adapter	120W HP Smart AC Adapter

Ports & Interfaces

USB Ports	4 USB 2.0 ports
HDMI Port	Yes
VGA Port	Yes
eSATA Port	Yes
Audio Ports	Stereo microphone in, stereo headphone/line out

Weight and Dimensions

Height	1.1 in (at front) / 28.2 mm (at front)
Width	14.0 in / 355.0 mm
Depth	10.4 in / 263.5 mm
Weight	Starting at 6.3 lbs / 2.86 kg
