HP EliteBook 8570w Quickspecs

At A Glance
Windows 8 versions, Windows 7 versions or FreeDOS
Chiseled design with enhanced HP DuraCase, magnesium-reinforced chassis, wear-resistant
gunmetal color HP DuraFinish, radial spun finish, backlit HP logo, HP DisplaySafe frame, precision aluminum-alloy hinges, cast
titanium-alloy display latches, keyboard in full aluminum deck, chemically strengthened glass touchpad, and laser-precision
indicators
Designed to meet the military standard Mil-Std-810G for vibration, dust, altitude, and high temperature operation*
Workstation-caliber discrete graphics: AMD FirePro™ M4000 (1GB GDDR5), NVIDIA Quadro K1000M (2GB DDR3), NVIDIA Quadro
K2000M (2GB DDR3)
ISV certified to provide fast and reliable performance with workstation applications, including manipulation of 3D textures
Choice of 3rd generation Intel® Core™ i7 and i5 processors
Intel Core i7 with vPro and Core i5 with vPro technology (optional)
Intel Smart Response Technology support for higher system performance with a hard drive'
HP Performance Advisor for optimal configuration, compatibility and performance
Up to four SODIMMs on configurations with quad-core processor, for system memory up to 32 GB
Supports multi-display when using an HP Advanced Docking Station (sold separately)
DisplayPort for high resolution support
SRS Premium Sound PRO optimized for high fidelity audio
Choice of battery solutions: 8-cell (83 WHr) or 8-cell (75 WHr) HP Long Life Battery, combined with optional external batteries
for extended life.
Choice of two optional external batteries for extended battery life
HP Peak Power Manager (web download) and HP Power Assistant (Windows 7 only) allow you to conserve power, stretch battery
run-time, accurately monitor the energy usage of the PC and up to four select HP external monitors, and report workforce power
consumption.
4 discrete buttons with LED indicator for convenient one touch access - Wireless On/Off, Volume Mute, Web browser, Calculator
Widescreen 15.6-inch diagonal LED-backlit display:
HD+ wide viewing angle, FHD wide viewing angle, or FHD ultra wide viewing angle with HP DreamColor
Upgrade Bay for optical drive, optional second hard drive, or weight saver
Flexible wireless connectivity options:
Optional integrated wireless mobile broadband module support
Integrated Intel Centrino® 802.11 a/b/g/n 2x2 or a/b/g/n 3x3, or Broadcom 802.11 a/b/g/n 2x2 wireless LAN module
Bluetooth® v4.0
Choice of 7200 rpm user-removable hard drive up to 750 GB with HP 3D DriveGuard protection,
or SATA 6 Gb/s 128/180 GB Solid State Drive or 256 GB SED Solid State Drive
Security features including HP ProtectTools, with central management across HP and non-HP client PCs
Low halogen **, ENERGY STAR qualified and EPEAT Gold registered in the U.S. EPEATstatus varies by country- please see
epeat.net.
* Testing was not intended to demonstrate fitness for DOD contracts requirements or for military use. Test results are not a guarantee
of future performance under these test conditions.
** External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be
Low Halogen.
QuickSpecs
HP EliteBook 8570w Mobile Workstation
Overview
DA - 14315 North America — Version 15 — May 8, 2013 Page 4

HP EliteBook 8570w Specifications

General

Bus type	DMI
Stepping	E1
Tjunction	105 °C
Processor cache	8 MB
Processor cores	4
Processor model	i7-3820QM
System bus rate	5 GT/s
Processor family	Intel High End Desktop Processors
Processor series	Intel Core i7-3800 Mobile Series
Processor socket	BGA 1224
Processor threads	8
Processor codename	Ivy Bridge
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Thermal Design Power (TDP)	45 W
Number of processors supported	1
CPU multiplier (bus/core ratio)	27
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	CD-RW/DVD Combo
Card reader integrated	Yes
Total storage capacity	750 GB
Compatible memory cards	MMC, SD
Display diagonal	15.6 \
Display resolution	- pixels
LightScribe	-
Graphics card family	Intel, NVIDIA
Intel segment tagging	Enterprise
On-board graphics card ID	0x166
Discrete graphics card model	NVIDIA® Quadro® K3000M
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Audio system	SRS Premium PRO
Number of built-in speakers	2
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Professional
Form factor	Clamshell
Product color	Black
Country of origin	China
Battery life (max)	- h
AC adapter power	200 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Processor code	SR0MK
Processor ARK ID	64889
Processor package size	37.5 x 37.5 (rPGA988B); 31.0 x 24.0 (BGA1224) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	382 mm
Width	345 mm
Height	25.75 mm
Weight	3000 g
