Spare part
number
Description
583053-001 Intel Quad Core i7 820QM 1.73-GHz (turbo up to 3.06-GHz) processor, 8-MB L2 cache, 8 threads, 45-W
(supports Intel Turbo Boost Technology, includes replacement thermal material)
586170-001 Intel Quad Core i7 720Qm 1.66-GHz (turbo up to 2.80-GHz) processor, 8-MB L2 cache, 8 threads, 45-W
(supports Intel Turbo Boost Technology, includes replacement thermal material)
587259-001 Intel Dual Core i7 620M 2.66-GHz (turbo up to 3.33-GHz) processor, 4-MB L2 cache, 4 threads, 35-W
(supports Intel Turbo Boost Technology, includes replacement thermal material)
590663-001 Intel Quad Core i7 920XM 2.00-GHz (turbo up to 3.20-GHz) extreme processor, 8-MB L2 cache, 8 threads,
55-W (supports Intel Turbo Boost Technology, includes replacement thermal material)
592078-001 8-cell, 68-Wh, Li-ion battery
594187-001 Intel Dual Core i5 520M 2.40-GHz (turbo up to 2.93-GHz) processor, 3-MB L2 cache, 4 threads, 35-W
(supports Intel Turbo Boost Technology, includes replacement thermal material)
594188-001 Intel Dual Core i5 540M 2.53-GHz (turbo up to 3.06-GHz) processor, 3-MB L2 cache, 4 threads, 35-W
(supports Intel Turbo Boost Technology, includes replacement thermal material)
595698-001 System board for use with computer models equipped with Intel Dual Core processors in all countries and
regions except the People's Republic of China and Russia: (includes replacement thermal material)
595700-001 System board for use with computer models equipped with Intel Quad Core processors in all countries and
regions except the People's Republic of China and Russia: (includes replacement thermal material)
595702-001 17.0-in, WXGA+ WVA AntiGlare LED display assembly without webcam (includes the display panel cable,
3 WLAN antenna transceivers and cables, and 2 WWAN antenna transceivers and cables)
595703-001 17.0-in, WSXGA+ WVA AntiGlare LED display assembly without webcam (includes the display panel cable,
3 WLAN antenna transceivers and cables, and 2 WWAN antenna transceivers and cables)
595704-001 17.0-in, WUXGA+ WVA AntiGlare LED display assembly without webcam (includes the display panel cable,
3 WLAN antenna transceivers and cables, and 2 WWAN antenna transceivers and cables)
595706-001 17.0-in, WXGA+ WVA AntiGlare LED display assembly with webcam (includes the display panel cable, 3
WLAN antenna transceivers and cables, and 2 WWAN antenna transceivers and cables)
595707-001 17.0-in, WSXGA+ WVA AntiGlare LED display assembly with webcam (includes the display panel cable, 3
WLAN antenna transceivers and cables, and 2 WWAN antenna transceivers and cables)
595708-001 17.0-in, WUXGA+ WVA AntiGlare LED display assembly with webcam (includes the display panel cable, 3
WLAN antenna transceivers and cables, and 2 WWAN antenna transceivers and cables)
596039-001 Screw Kit
596040-001 Cable Kit
NOTE: See
Cable Kit on page 27 for more Cable Kit spare part information.
596041-001 Wireless Antenna Kit (includes WLAN antenna transceivers and cables and WWAN antenna transceivers
and cables)
596042-001 Display panel cable (includes webcam module cable and ambient light sensor board cable)
596043-001 Microphone
596044-001 Plastics Kit
NOTE: See
Plastics kit on page 31 for more Plastics Kit spare part information.
596045-001 Switch cover (includes capacitive board and cable and power button board and cable)
596046-001 Graphics board heat sink for use only with computer models equipped with ATi graphics subsystems
(includes 5 replacement thermal pads)
34 Chapter 3 Illustrated parts catalog ENWW
