HP EliteBook Folio 1040 G1 - Page 13

180 GB* M.2 SED Solid
State Drive
Drive Weight 10 Grams
Capacity 180 GB
Height 0.091 in (2.3 mm)
Width 0.87 in (22 mm)
Interface SATA 3 (6 Gb/s)
Performance Maximum Sequential
Read
Maximum Sequential Write
Up to 540 MB/s Up to 490 MB/s
Logical Blocks 351,651,888
Operating Temperature 32° to 158°F (0° to 70°C) [case temp]
Features ATA Security; ATA-8, SATA 3.0; DIPM; TRIM; TCG Opal 1.0
SATA 6 Gb/s 256 GB * ,
2.5-inch SATA SED
Solid State Drive
(available March 2014)
Drive Weight TBD Grams
Capacity 256 GB
Height TBD in (TBD mm)
Width TBD in (TBD mm)
Interface SATA 3 (6 Gb/s)
Performance Maximum Sequential
Read
Maximum Sequential Write
Up to TBD MB/s Up to TBD MB/s
Logical Blocks TBD
Operating Temperature TBD
Features TBD
SECURITY
HP Fingerprint Reader Mobile Voltage
Operation
3.0V-3.6V
Operating Temperature 14° - 167°F (-10° - 75°C)
Current Consumption
36 mA peak
Low Latency Wait for
Finger
950 uA
Capture Rate 3000. lines/sec
ESD Resistance IEC 61000-4-2 4B (±15KV)
Detection Matrix 200*1 (plus another secondary line)
508 dpi
12*3 mm sensor area
QuickSpecs
HP EliteBook Folio 1040 G1 Notebook PC
Technical Specifications
DA - 14804 Worldwide QuickSpecs — Version 3 — 1.24.2014 Page 13
