L-MF877-00 Page 3

Template Revision B

PSG instructions for this template are available at EL-MF877-01

Figure1 Disconnect the AC adapter cable. Figure2 Remove the thumb screw.

Figure3 Remove the Access Panel. F

igure4 Loose the anchor point of front bezel.

Figure5 Remove the Front Bezel.

Fig

ure6 Disconnect HDD SATA cable.
