HP EliteDesk 705 G2

EL-MF877-00 Page 13
Template Revision B
PSG instructions for this template are available at EL-MF877-01
10. Remove front bezel
1
Lift up 3 latches first
then pressing 2
latches in the side of
front bezel for
escaping from
chassis as photo1
shown
2
Take out front bezel
photo2 shown
