HP EliteDesk 705 G2 Disassembly Instructions

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Description #1
Description #2
Description #3
Description #4
Description #5
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove access panel
2. Remove HDD and HDD FAN for Dolomite and Hood Sensor
3. Remove system fan
4. Remove heat sink from M/B
5. Remove WLAN Card from M/B
6. Remove ambient sensor fly cable and Speaker cable
7. Remove M/B and battery
8. Remove Memory
9. Remove Rear IO (HDMI/DP/SERIAL) card and M.2 card
10. Remove front bezel
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).

HP EliteDesk 705 G2 Specifications

General

Processor family	AMD
Built-in processor	No
Audio system	Realtek ALC221
Optical drive type	DVD Super Multi
Motherboard chipset	AMD A58
Compatible processor series	AMD A
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	1.2
Memory slots type	DIMM
Number of memory slots	4
Maximum internal memory	32 GB
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
PCI Express x1 slots	2
PCI Express x16 slots	1
HDMI ports quantity	0
PS/2 ports quantity	11
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Chassis type	SFF
Cooling type	-
Product type	PC barebone
Product color	Black
Power supply	200 W
Power supply type	Internal power supply unit
Compatible operating systems	- Windows 10 Pro 64 bit, Windows 10 Home 64 bit, Windows 8.1 Pro 64 bit, Windows 8.1 64 bit, Windows 7 Professional 64 bit, Windows 7 Professional 32 bit, Windows 7 Professional 64 bit, Windows 7 Professional 32 bit - NeoKylin Linux 64 - FreeDOS 2.0
Sustainability certificates	ENERGY STAR
Certification	EPEAT Gold

Weight and Dimensions

Depth	380 mm
Width	338 mm
Height	100 mm
Weight	6600 g
