HP EliteDesk 705 G2

EL-MF877-00 Page 4
Template Revision B
PSG instructions for this template are available at EL-MF877-01
2 .Remove HDD and HDD FAN for Dolomite and Hood
Sensor
1
Lift HDD latch up
then press HDD the
forward for escaping
from cage as photo1
shown
2.
Pull the connector
first then pull HDD
SATA FFC cable out
of motherboard as
photo2 shown
Push the latch
PUSH
PULL
