HP EliteDisplay E222 User Manual

QuickSpecs
HP EliteDisplay E222 21.5-inch Monitor
Technical Specifications
c04820063 — DA15428 — Worldwide — Version 1 — September 29, 2015
Page 4
Models:
M1N96AA - HP EliteDisplay E222 21.5-inch Monitor
Panel
Type
21.5-inch IPS w/LED backlight
Viewable Image Area
(diagonal)
54,61 cm (21.5-inch) widescreen; diagonally measured
Panel Active Area
(W × H)
47,06 x 26,77 cm (18.74 x 10.54 in)
Resolution
1920 x 1080 @ 60 Hz
Aspect Ratio
16:9
Viewing Angle*
Up to 178° horizontal/178° vertical typical
Brightness*
250 cd/m
2
Contrast Ratio
(Typical)*
1000:1 Static; 5,000,000:1 Dynamic (DCR)
Response Times*
7 ms gray to gray
Pixel Pitch*
0.24795 (H) x 0.24795 (V)mm
Pixels Per Inch (PPI)*
102
Backlight Lamp Life
(to half brightness)*
30,000 hours minimum
Color Support*
Up to 16.7 million colors with the use of FRC technology
Color Gamut (Typical)*
72%
* Performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
User Controls
Buttons or Switches
Dynamically adjust depending upon OSD screen selected
Languages
10 (English, Spanish, German, French, Italian, Netherlands, Portuguese,
Japanese, T-Chinese and S-Chinese)
On Screen Display
(OSD) User Controls
Brightness, Contrast, Color Control, Input Control, Image Control, Power
Control, Menu Control, Management, Language, Information
Signal Interface/
Performance
Horizontal Frequency
30-80 kHz
Vertical Frequency
50-75 Hz
Native Resolution
1920 x 1080 @ 60 Hz*
*The video card of the connected PC must be capable of supporting
1920 x 1080 at 60 Hz and include 1VGA or 1 DisplayPort or 1 HDMI
outputs to drive the monitor at the Preferred Mode.
Preset Graphic Modes
(non-interlaced)
1920 X 1080 @ 60 Hz
1680 X 1050 @ 60 Hz
1600 X 900 @ 60 Hz
1440 X 900 @ 60 Hz
1280 X 1024 @ 60 Hz
1280 X 800 @ 60 Hz
1280 X 720 @ 60 Hz
1024 X 768 @ 60 Hz

HP EliteDisplay E222 Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Screen shape	Flat
Display diagonal	21.5 \
Display technology	LED
Vertical scan range	50 - 75 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	267.786 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476.064 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+)
On/off switch	Yes
Product color	Black, Silver
Country of origin	China
Market positioning	Business
Pivot angle	0 - 90 °
Tilt angle range	-5 - 25 °
Height adjustment	150.92 mm
Panel mounting interface	100 x 100 mm
USB hub version	2.0
USB Type-A downstream ports quantity	2
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	35 W
Power consumption (off)	0.3 W
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
NVIDIA G-SYNC	-

Weight and Dimensions

Depth (with stand)	189 mm
Height (with stand)	333.5 mm
Weight (with stand)	5270 g
Depth (without stand)	49.8 mm
Width (without stand)	513.7 mm
Height (without stand)	316.9 mm
Weight (without stand)	3260 g
