HP EliteDisplay E222 User Manual

QuickSpecs
HP EliteDisplay E222 21.5-inch Monitor
Technical Specifications
c04820063 — DA15428 — Worldwide — Version 1 — September 29, 2015
Page 5
800 X 600 @ 60 Hz
640 X 480 @ 60 Hz
Maximum Pixel Clock
Speed
170 MHz
Anti-Glare
Yes
Video/Other Inputs
Plug and Play
Yes
Input Connectors
(1) DisplayPort 1.2, (1) HDMI, (1) VGA
HDCP support on DisplayPort and HDMI
USB
(3) USB 2.0 (two downstream and one upstream)
Cables Included
(1) DisplayPort 1,8 m (5.9 ft) ; (1) VGA 1,8 m (5.9 ft); (1) USB cable 1,8 m
(5.9 ft)
Audio
N/A
Multimedia
Speakers
N/A
Power
Power Supply
Internal
Input Power
100 - 240 VAC 50/60 Hz
Maximum Power
35 W
Typical Power
23 W
Sleep Power
0.5 W (standby)
Power Cable Length
1.9 m (6.2 ft)
Mechanical
Dimensions
(W × D × H)
Unpacked w/stand
51,37 x 18,9 x 33,35 cm
(0 degrees & lowest position)
(20.22 x 7.44 x 13.13 in)
51,37 x 18,9 x 48,90 cm
(0 degrees & highest position)
(20.22 x 7.44 x 19.25 in)
Unpacked w/o stand
(head only)
51,37 x 4,98 x 31,69 cm
(20.22 x 1.96 x 12.48 in)
Packaged
60 x 22,5 x 40 cm
(23.62 x 8.86 x 15.75 in)
Weight
Head Only
3,26 kg (7.19 lb)
Unpacked with stand
5,27 kg (11.62 lb)
Packaged
7,18 kg (15.83 lb)
Ergonomic Features
Detachable Stand
Yes
Height Adjustment
Yes, 150 mm
Tilt Range
-5° to +25°
Swivel
±45°
Pivot
90°
Environmental
Temperature -
Operating
5° to 35° C (41° to 95° F)
Temperature - Non-
operating
–20° to 60° C (-4° to 140° F)

HP EliteDisplay E222 Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Screen shape	Flat
Display diagonal	21.5 \
Display technology	LED
Vertical scan range	50 - 75 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	267.786 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476.064 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+)
On/off switch	Yes
Product color	Black, Silver
Country of origin	China
Market positioning	Business
Pivot angle	0 - 90 °
Tilt angle range	-5 - 25 °
Height adjustment	150.92 mm
Panel mounting interface	100 x 100 mm
USB hub version	2.0
USB Type-A downstream ports quantity	2
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	35 W
Power consumption (off)	0.3 W
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
NVIDIA G-SYNC	-

Weight and Dimensions

Depth (with stand)	189 mm
Height (with stand)	333.5 mm
Weight (with stand)	5270 g
Depth (without stand)	49.8 mm
Width (without stand)	513.7 mm
Height (without stand)	316.9 mm
Weight (without stand)	3260 g
