HP EliteDisplay E222 User Manual

QuickSpecs
HP EliteDisplay E222 21.5-inch Monitor
Technical Specifications
c04820063 — DA15428 — Worldwide — Version 1 — September 29, 2015
Page 6
Humidity - Operating
20% to 80% non-condensing
Humidity - Non-
operating
5% to 95%, 38.7° C max wet-bulb
Altitude - Operating
0 to 5,000 m (0 to 16,404 ft)
Altitude – Non-
operating
0 to 12,192 m (0 to 40,000 ft)
White LED Backlights
Yes
CCFL Panel
No
Arsenic-Free Display
Glass
Yes
Low Halogen
1
Yes (except cables)
Mercury-Free Display
Backlighting
Yes
Options
HP Adjustable Dual
Display Stand—Part
Number AW664AA
Premium space-saving dual screen solution provides access to more
monitor real estate and makes it possible to manage multiple
applications simultaneously. Weight adjustable for dual monitors from
17-24”. Rotate displays into portrait/landscape positions.
HP Single Monitor
Arm—Part number
BT861AA
The flexible design of the HP Single Monitor Arm provides a seemingly
endless range of display adjustments with an amazing 13 inches of lift,
75 degrees of tilt, and 360 degrees of pan and rotation – all at your
fingertips -- helping you stay comfortable and productive throughout
the day.
HP LCD Monitor Quick
Release — Part number
EM870AA
4
An easy-to-use, VESA-compliant, LCD monitor mounting solution that
allows you to quickly and securely attach an LCD monitor to a variety of
stands, brackets, arms or wall mounts. For more information, refer to
this product's QuickSpecs document.
HP LCD Speaker Bar—
Part number NQ576AA
Powered directly by the connected PC, the Speaker Bar seamlessly
attaches to the monitor's lower bezel to bring full audio support to
select HP flat panel monitors. Features include dual speakers with full
sound range and dual external headphone jacks. Sold separately. For
more information, refer to the product’s QuickSpecs.
HP Business PC Security
Lock v2 Kit— Part
number N3R93AA
Help prevent chassis tampering and secure your PC and display in
workspaces and public areas with the HP Business PC Security Lock v2
Kit.
HP PC Mounting Bracket
for Monitors— Part
number N6N00AA
Customize an altogether better solution with the HP PC Mounting
Bracket for Monitors, which lets you attach your HP Desktop Mini, HP
Chromebox, or select HP Thin Client directly behind select HP Z Displays
and EliteDisplays.
HP UHD USB Graphics
Adapter — Part number
N2U81AA
Just plug the adapter into any USB 2.0 or 3.0 port on your PC and
connect the DisplayPort connector on the other end to your EliteDisplay
display.
What’s in the box?
Monitor and
Accessories
HP EliteDisplay E222 21.5-inch Monitor; AC power cord (1.8m), 5.9 ft;
DisplayPort cable (1.8m), 5.9 ft; VGA cable (1.8m); 5.9 ft, USB cable
(1.8m), 5.9 ft
Documentation
CD (includes user guide, warranty, drivers)

HP EliteDisplay E222 Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Screen shape	Flat
Display diagonal	21.5 \
Display technology	LED
Vertical scan range	50 - 75 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	267.786 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476.064 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+)
On/off switch	Yes
Product color	Black, Silver
Country of origin	China
Market positioning	Business
Pivot angle	0 - 90 °
Tilt angle range	-5 - 25 °
Height adjustment	150.92 mm
Panel mounting interface	100 x 100 mm
USB hub version	2.0
USB Type-A downstream ports quantity	2
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	35 W
Power consumption (off)	0.3 W
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
NVIDIA G-SYNC	-

Weight and Dimensions

Depth (with stand)	189 mm
Height (with stand)	333.5 mm
Weight (with stand)	5270 g
Depth (without stand)	49.8 mm
Width (without stand)	513.7 mm
Height (without stand)	316.9 mm
Weight (without stand)	3260 g
