HP EliteDisplay E232 User Manual

About This Guide
This guide provides information on monitor features, setting up the monitor, and technical specifications.
WARNING! Indicates a hazardous situation that, if not avoided, could result in death or serious injury.
CAUTION: Indicates a hazardous situation that, if not avoided, could result in minor or moderate injury.
NOTE: Contains additional information to emphasize or supplement important points of the main text.
TIP: Provides helpful hints for completing a task.
This product incorporates HDMI technology.
iii

HP EliteDisplay E232 Specifications

General

3D	No
Screen shape	Flat
Display surface	Matt
Display diagonal	23 \
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Viewable size, vertical	286.416 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	509.184 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 1024 x 768 (XGA), 1024 x 800, 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
AC adapter included	Yes
Certification	CE CB KC/KCC NOM ICE TUV-S ISO 9241-307 EAC UL CSA PSB CCC CEL CECP SEPA TCO Certified Edge ISC VCCI FCC BSMI Vietnam MEPS Australian-New Zealand MEPS WEEE Microsoft WHQL Certification (Windows 10, Windows 8.1 and Windows 7)
Product color	Black
Country of origin	China
Market positioning	Business
USB hub version	2.0
USB Type-A downstream ports quantity	2
Pivot angle	0 - 90 °
Tilt angle range	-5 - 25 °
Cables included	AC, USB, VGA
Sustainability certificates	EPEAT Gold, ENERGY STAR
AC input voltage	100 - 240 V
Power consumption (off)	0.23 W
Power consumption (standby)	0.25 W
Power consumption (typical)	19 W

Weight and Dimensions

Depth (without stand)	49.6 mm
Width (without stand)	549.3 mm
Height (without stand)	336.9 mm
Weight (without stand)	3630 g
