HP EliteDisplay E240e - Main Board; Disassembly Steps

HP EliteDisplay E240e
5 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
2
Remove the
REAR_COVER
Use the tool to
remove the Rear
cover
Separate the
MAINFRAME
and PANEL
Tear out all
tapes.
Remove the
screws and
disconnect the
connectors
to separate the
MAINFRAME
and PANEL.
Remove the
MAIN BOARD
and POWER
BOARD
Remove the
MAYLR &
screws and
disconnect the
connectors to
remove the
MAIN BOARD
Power board and
USB board
