HP EliteDisplay S230tm User Manual

2 Setting up and using the monitor
To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other
attached devices, and then follow the instructions below.
Rear components
Component Description
1 DC power connector Connects the DC power cable to the monitor.
2 DisplayPort connector Connects the DisplayPort cable to the monitor.
3 DVI-D connector Connects the DVI-D cable to the monitor.
4 Audio In connector Connects the audio cable from a host computer to the monitor .
5 USB upstream connector Connects the USB cable to the monitor's touch screen USB
connector and to a host USB port/hub.
NOTE: A USB connection between the monitor and computer
is required for webcam and touch functionality.
Rear components 3

HP EliteDisplay S230tm Specifications

General

Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	23 \
Touch technology	Multi-touch
Touchscreen type	Tabletop
Display brightness	220 cd/m²
Vertical scan range	50 - 76 Hz
Horizontal scan range	24 - 94 kHz
Touchscreen technology	Optical imaging
Contrast ratio (typical)	1000:1
Display diagonal (metric)	58.42 cm
Product color	Black, Silver
Country of origin	China
Dimensions (W x D x H) with stand	599.3 x 69.5 x 409.2 mm
DVI-D ports quantity	1
Tilt angle range	15 - 70 °
Panel mounting interface	100 x 100 mm
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
OmniTapps Multitouch compatibility	No
RMS rated power	2 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	69.5 mm
Width (with stand)	599.3 mm
Height (with stand)	409.2 mm
Weight (with stand)	6500 g
Depth (without stand)	40.5 mm
Weight (without stand)	5500 g
