Right side
Component Description
(1) Optical drive Reads and writes to an optical disc.
(2) Optical drive light
●
Green: The optical drive is being accessed.
●
Off: The optical drive is idle.
(3) Optical drive eject button Ejects the optical disc.
(4) USB port Connects an optional USB device.
(5) AC adapter light
●
White: The computer is connected to external power
and the battery is fully charged.
●
Blinking white: The battery is low.
●
Amber: A battery is charging.
●
Off: The computer is not connected to external power.
(6) Power connector Connects an AC adapter.
(7) Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a deterrent,
but it may not prevent the computer from being mishandled
or stolen.
Right side 9
