5. Disconnect the webcam cable (5) from the system board and release it from the clips that attach
it to the system board.
CAUTION: Support the display assembly when removing the display screws in the following
steps. Failure to support the display assembly can result in damage to the assembly and other
components.
6. Remove the six black Phillips PM2.5×7.0 screws (1) that secure the display assembly to the
computer.
7. Lift the display panel (2) straight up to remove it.
Reverse this procedure to install the display assembly.
Component replacement procedures 69
