Item Description Spare part number
(4) Top cover (includes TouchPad and cable)
For use only in computer models not equipped with a Web camera 454936-001
For use only in computer models equipped with a Web camera 466649-001
(5) Caps lock LED board (includes cable)
454948-001
(6) Speakers
454946-001
(7) Fan
454944-001
(8) Power connector cable
454945-001
Plastics Kit (see Plastics Kit on page 22 for more information)
454937-001
(9a) Hard drive bay cover
(9b) Memory/wireless module compartment cover
(10) System boards (include replacement thermal material and modem cable)
For use in computer models not equipped with a Web camera:
●
Equipped with Intel Core 2 Duo and Core Duo processors and a card reader board
453494-001
●
Equipped with Intel Core 2 Duo and Core Duo processors, but not a card reader board
445882-001
●
Equipped with Intel Celeron M processors and a card reader board
453495-001
●
Equipped with Intel Celeron M processors, but not a card reader board
454883-001
For use in computer models equipped with a Web camera:
●
Equipped with Intel Core 2 Duo and Core Duo processors and a card reader board
462439-001
●
Equipped with Intel Core 2 Duo and Core Duo processors, but not a card reader board
462441-001
●
Equipped with Intel Celeron M processors and a card reader board
462440-001
●
Equipped with Intel Celeron M processors, but not a card reader board
462442-001
Modem cable (not illustrated)
454950-001
(11) USB board (includes cable)
454941-001
(12) Card reader board (for use only with system boards with spare part numbers
453494-001, 453495-001, 462439-001, and 462440-001)
454949-001
(13) Processors (include replacement thermal material)
Intel Core 2 Duo T8300 (2.40-GHz, 3 MB of L2 cache, 800-MHz FSB) 459798-001
Intel Core 2 Duo T8100 (2.10-GHz, 3 MB of L2 cache, 800-MHz FSB) 459797-001
Intel Core 2 Duo T7250 (2.00-GHz, 2 MB of L2 cache, 800-MHz FSB) 454320-001
Intel Core 2 Duo T7100 (1.80-GHz, 2 MB of L2 cache, 800-MHz FSB) 448149-001
Intel Core Duo T5750 (2.00-GHz, 2 MB of L2 cache, 667-MHz FSB) 462353-001
Intel Core Duo T5450 (1.67-GHz, 2 MB of L2 cache, 667-MHz FSB) 451597-001
Intel Core Duo T2370 (1.73-GHz, 1 MB of L2 cache, 667-MHz FSB) 462354-001
Intel Core Duo T2330 (1.60-GHz, 1 MB of L2 cache, 667-MHz FSB) 455944-001
16 Chapter 3 Illustrated parts catalog
