Note 2 Localization required. (See Localization Menu for list.)
Note 3 Only 1 JD183A or JG136A can be connected per switch.
External/Redundant Power Cables
HP X290 1000 A JD5 2m RPS Cable JD187A
HP X290 500/800 1m RPS Cable JD190A
Enter the following menu selections as integrated to the CTO Model X above if order is factory built.
Modules
(Switch JE066x and JE067x ) No Modules supported
(All other Switches ) System (std 0 // max 2) User Selection (min 0 // max 2)
HP 5500 2-port 10GbE XFP Module JD359B
min=0 \ max=2 XFP Transceivers See Configuration
Note:2, 5, 6
HP 5500 2-port 10GbE Local Connect Mod JD360B
min=0 \ max=2 CX4 Cables See Configuration
Note:4, 5, 6
HP 5500 1-port 10GbE XFP Module JD361B
min=0 \ max=1 XFP Transceivers See Configuration
Note:2, 5, 6
HP 5500/5120 2-port 10GbE SFP+ Module JD368B
min=0 \ max=2 SFP+ Transceivers See Configuration
Note:1, 5, 6
HP 5500/4800 2-port GbE SFP Module JD367A
min=0 \ max=2 SFP Transceivers See Configuration
Note:3, 5, 6
HP 5500/5120 2p 10GBASE-T Module JG535A
No Transceivers See Configuration
Note:5, 6
Configuration Rules:
Note 1 The following Transceivers install into this Module: (Use #0D1 if switch is CTO)
HP X130 10G SFP+ LC ER 40km Transceiver JG234A
HP X130 10G SFP+ LC SR Transceiver JD092B
HP X130 10G SFP+ LC LRM Transceiver JD093B
HP X130 10G SFP+ LC LR Transceiver JD094B
QuickSpecs
HP 5120 EI Switch Series
Configuration
DA - 13850 Worldwide — Version 26 — April 15, 2014 Page 17
