HP L1502 LCD
THE DISPLAY DATA CHANNEL ( DDC ) 2B CONTENT
(FOR analog)
Vendor/Product Identification
ID Manufacturer Name : HWP
ID Product Code : 2600 (HEX.)
ID Serial Number : B001 (HEX.)
Week of Manufacture : 25
Year of Manufacture : 2003
EDID Version, Revision
Version : 1
Revision : 3
Basic Display Parameters/Features
Video Input Definition : Analog Video Input
0.700V/0.000V (0.70Vpp)
without Blank-to-Black Setup
Separate Sync
without Composite Sync
without Sync on Green
no Serration required
Maximum H Image Size : 30
Maximum V Image Size : 22
Display Transfer Characteristic : 2.2
(gamma)
Feature Support (DPMS) : Standby
Suspend
Active Off
Display Type : RGB color display
Preferred Timing Mode : Detailed timing block 1
Color Characteristics
Red X coordinate : 0.635
Red Y coordinate : 0.343
Green X coordinate : 0.30
2
Green Y coordinate : 0.581
Blue X coordinate : 0.145
Blue Y coordinate : 0.096
White X coordinate : 0.313
White Y coordinate : 0.329
Established Timings
Established Timings I : 720 x 400 @70Hz (IBM,VGA)
640 x 480 @60Hz (IBM,VGA)
640 x 480 @72Hz (VESA)
640 x 480 @75Hz (VESA)
800 x 600 @60Hz (VESA)
Established Timings II : 800 x 600 @72Hz (VESA)
800 x 600 @75Hz (VESA)
832 x624@75Hz (Apple,Mac II)
1024x768 @60Hz (VESA)
1024x768 @70Hz (VESA)
1024x768 @75Hz (VESA)
Manufacturer's timings :
Standard Timing Identification #1
Horizontal active pixels : 1024
Aspect Ratio : 4:3
Refresh Rate : 60
Detailed Timing #1
Pixel Clock (MHz) : 65
H Active (pixels) : 1024
H Blanking (pixels) : 320
V Active (lines) : 768
V Blanking (lines) : 38
H Sync Offset (F Porch) (pixels): 24
H Sync Pulse Width (pixels) : 136
V Sync Offset (F Porch) (lines) : 3
V Sync Pulse Width (lines) : 6
H Image Size (mm) : 300
V Image Size (mm) : 220
H Border (pixels) : 0
V Border (lines) : 0
Flags : Non-interlaced
: Normal Display, No stereo
: Digital Separate sync.
: Negative Vertical Sync.
: Negative Horizontal Sync.
Monitor Descriptor #2
Monitor Range Limits
Min. Vt rate Hz : 56
Max. Vt rate Hz : 76
Min. Horiz. rate kHz : 30
Max. Horiz. rate kHz : 61
Max. Supported Pixel : 80
No secondary GTF timing formula supported.
Monitor Descriptor #3
Monitor Name : hp L1502
Monitor Descriptor #4
Serial Number : CNP325B001
Extension Flag : 0
Check sum : E3 (HEX.)
**********************************************************************
EDID data (128 bytes)
**********************************************************************
0: 00 1: ff 2:ff 3:ff 4:ff 5:ff 6:ff 7:00
8: 22 9: f0 10: 00 11: 2612: 01 13: b0 14: 00 15:00
16: 19 17: 0d 18: 01 19: 03 20: 68 21: 1e 22:16 23: 78
24: ea 25:b726: 25 27:a228: 57 29: 4d 30: 94 31: 25
32: 18 33: 50 34: 5435: ad 36: ee 37: 00 38: 61 39: 40
40: 01 41: 01 42: 01 43: 01 44: 01 45: 01 46: 01 47:01
48: 01 49: 01 50: 01 51: 01 52:01 53: 01 54: 64 55:19
56: 00 57:40 58: 41 59: 00 60: 26 61: 30 62: 18 63: 88
64: 36 65: 00 66: 2c67: dc 68: 10 69: 00 70: 00 71: 18
72:00 73: 00 7
4: 00 75:fd 76: 00 77:38 78: 4c 79: 1e
80: 3d 81: 08 82: 00 83: 0a 84: 2085: 20 86: 2087: 20
88: 20 89: 20 90: 00 91: 00 92: 00 93: fc 94: 00 95:68
96: 7097: 20 98: 4c 99: 31 100: 35 101: 30 102:32 103: 0a
104: 20105: 20 106: 20107: 20 108: 00 109: 00 110: 00 111: ff
112: 00 113: 43 114: 4e 115: 50 116: 33 117:32 118: 35 119: 42
120: 30 121: 30 122:31123: 0a 124: 20125: 20126: 00 127:e3
