Page #51 background imageLoading...
Page #51 background image
51
HP L1502 LCD
GENERAL PRODUCT SPECIFICATION
15 inch LCD MONITOR
TYPE : AJ6S50/02
BRAND : HP (L1502)
8639 000 15367
2004-04-23
2004-04-23
590
2
18
HP WU
Go to cover page
1. Product Profile
Monitor name : HP L1502
Style : Integrated tilt base
Scanning frequencies : 30 -61KHz(Horizontal), 56 -76 Hz(Vertical)
Video resolution : XGA,1024x768
Video dot rate : 80 MHz
1.1 User controls and indicators:
Front: -DCon/off switch
-Power LED
- OSD function 3 keys
Rear: -D-sub cable
- AC inlet
1.2 Approved Controller ASICS
Genesis 2116RSDS
1.3 Approved Panel Specification
Table 1.
Vendor LGPL CPT
Updated date 2002-Aug-30 2002-Dec.-13
Physical Dimension (mm)
Model Number LS150X08 CLAA150XP01
Diagonal Size --- inch 15.0" 15.0"
Active Area (W x H ) 304.1x228.1 304.1x228.1
Display Pixels (W x H ) 1024(x3)x768 1024(x3)x768
Pixel Pitch (0.099x3)x0.297(0.099x3)x0.297
Weight 1000g 1060g
Optical Characteristics
Number of Colors 6 bits (262K) 6 bits (262K)
Contrast Ratio 400(typ),250(min) 500(typ),250(min)
ViewingAngle(L/R) --- C/R>10 65/65(typ) 70/70(typ)
ViewingAngle(U/D) --- C/R>10 45/55(typ) 65/65(typ)
Luminance --- nits 250(typ),200(min) 250(typ),200(min)
White(x,y) 313 , 329 313, 329
Red(x,y) 631,347 641,345
Green ( x , y ) 309, 583 305,567
