HP L1502 LCD
GENERAL PRODUCT SPECIFICATION
15 inch LCD MONITOR
TYPE : AJ6S50/02
BRAND : HP (L1502)
8639 000 15367
2004-04-23
2004-04-23
590
4
18
HP WU
Go to cover page
- Monitor displays Check Video Cable message.
- After 60 seconds, the Going to Sleep message is displayed for 3 seconds.
- After 3 seconds, Monitor enters the Sleep mode; Power LED is Amber
If the monitor is in Sleep mode, pressing any OSD button shall cause the OSD
message to be displayed for another 60 seconds. If the Power Saver feature is set to
off, then the Check Video Cable shall be continuously displayed with a moving
OSD box to prevent image retention on the LCD panel.
2.1.2 Signal Connector and Cable
All models shall include one analog video signal input.
The connector and cable requirements are specified below.
D-sub Connector and VGA I/F Cable
A signal cable shall be provided with the monitor and shall be black and 1.5 ± .05
meters long. One end shall have a molded-over, shielded, triple row, 15 position,
subminiature D connector. The D connection shall have captive screw locks, which
will be adequate for hand tightening. If a ferrite bead is required on the video
cable at the point it plugs into the PC, the bead can be no closer than 2 .60 (66mm)
from the VGA connector. The VGA connector cannot be any deeper than 2.0 (51mm).
2.1.3 Video Signal Pin Assignments
TABLE 1
ANALOG CONNECTOR PINOUT
PIN MNEMONIC SIGNAL
1RVRedVideo
2 GV Green Video/Sync on Green
3 BV Blue Video
4 NC None
5 GND Ground (DDC Return) or Cable detect
6 RG Red GND
7 GG Green GND
8BGBlueGND
9+5V+5V
10 SG Sync GND or Cable detect
11 NC None
12 SDA DDC Data
13 HS Horizontal Sync
14 VS Vertical Sync
15 SCL DDC Clock
""
"
"
"
"
"
"
