HP L1740 Service Manual

17" LCD Color Monitor HP L1740
4
2. LCD Monitor Description
The LCD Monitor will contain main board, power board, a key board which house the flat panel control logic, brightness
control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each
voltage.
Video signal, DDC
Power Board
(
Include ada
p
ter board
)
Flat Panel and
CCFL backlight
Main Board
RS232 Connector
For white balance
adjustment in
factory mode
HOST Computer
CCFT Drive.
AC-IN
110V-240V
Monitor Block Diagram
Keyboard

HP L1740 Specifications

General

3D	No
Response time	8 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Viewing angle, vertical	135 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	150 °
Digital vertical frequency	56 - 76 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1152 x 870, 1024 x 768 (XGA), 1360 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	2.0
DVI-I ports quantity	0
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (max)	60 W
Power consumption (average)	33 W
Power consumption (standby)	2 W
Power consumption (typical)	40 W
Product color	Black, White
Country of origin	China
Package weight	8800 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	248 mm
Height (with stand)	490 mm
Weight (with stand)	7000 g
Depth (without stand)	62 mm
Width (without stand)	371 mm
Height (without stand)	315 mm
Weight (without stand)	3760 g
