HP L1740 Service Manual

17" LCD Color Monitor HP L1740
54
14. Different Parts List
Diversity of T77CNNDKCKHFQE Compared with T77GNNDKCKHFQE
Location Part No. Description
CBPC6CNNHPQ2P MAIN BOARD
PWPC742CH1P POWER BOARD
89G179J30H711 FFC CABLE
705GH734010 ASS'Y
750GLB70A7P11Z000H PANEL CLAA170EA07P 000
C204 65G0603224 226029 CHIP 0.22UF 25V X7R
C233 65G0603224 226029 CHIP 0.22UF 25V X7R
C318 65G0603224 226029 CHIP 0.22UF 25V X7R
C523 65G0603224 226029 CHIP 0.22UF 25V X7R
D901 93G 6026W52T FR107
ZD975 93G 39GA26 T ZENER DIODE RLZ5.1B SEM
301 15G6340 4 MAIN FRAME
Diversity of T77ANNDKCKHFQE Compared with T77GNNDKCKHFQE
Location Part No. Description
CBPC6ANNHAQ1P MAIN BOARD
PWPC742AH1P POWER BOARD
705GH734009 ASS'Y
E750L 750GLU70G1D12Z000H PANEL M170EG01 VD00 AUO
Q23G3178690 8A LOGO
D901 93G 6026W52T FR107
301 15G6340 3 MAIN FRAME
Diversity of T76CNNDBCKHPQE Compared with T77GNNDKCKHFQE
Location Part No. Description
CBPC6CNNHPQ1P MAIN BOARD
PWPC1742CH1P POWER BOARD
41G7800690A18 QSG-EU
89G179J30H711 FFC CABLE
89G404A19N LS POWER CORD
705GH734010 ASS'Y
750GLB70A7P11Z000H PANEL CLAA170EA07P 000
Q41G160069044C DOC KIT1740 FOR EMEA
SMTC6CNNHPQ1P G1864-1-X-X-1-070122
CN401 33G3802 14 6065 14P/2.0MM
U501 56G1142 4 CY7C65640A-LFXC
Q501 57G 7602PH TRA PDTC114EK SC-59 PHI

HP L1740 Specifications

General

3D	No
Response time	8 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Viewing angle, vertical	135 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	150 °
Digital vertical frequency	56 - 76 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1152 x 870, 1024 x 768 (XGA), 1360 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	2.0
DVI-I ports quantity	0
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (max)	60 W
Power consumption (average)	33 W
Power consumption (standby)	2 W
Power consumption (typical)	40 W
Product color	Black, White
Country of origin	China
Package weight	8800 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	248 mm
Height (with stand)	490 mm
Weight (with stand)	7000 g
Depth (without stand)	62 mm
Width (without stand)	371 mm
Height (without stand)	315 mm
Weight (without stand)	3760 g
