HP L1740 Service Manual

17" LCD Color Monitor HP L1740
41
453 Q45G 88609 29 R PE BAG(EPE)
Q50G 505 19 BEND
CN402 33G3802 7 6176 WAFER EH 7
CN401 33G3802 14 6176 14P/2.0MM
CN302 33G801930F H6W34 FPC CONN .1.0MM 30P
40G 457624 1B CPU LABEL
40G 45762412B CBPC LABEL
C421 67G215V100 7R ELCAP 10UF +-20% 50V 10
C429 67G215V100 7R ELCAP 10UF +-20% 50V 10
C434 67G215V100 7R ELCAP 10UF +-20% 50V 10
C436 67G215V100 7R ELCAP 10UF +-20% 50V 10
C437 67G215V100 7R ELCAP 10UF +-20% 50V 10
C517 67G215V100 7R ELCAP 10UF +-20% 50V 10
C521 67G215V100 7R ELCAP 10UF +-20% 50V 10
C439 67G215V470 4R ELCAP 47UF +-20% 25V 10
C324 67G215Y4713RV ELCAP 470UF +-20% 16V 1
CN501 88G 350 1 TN USB CONN
CN502 88G 3512B1 CL USB CONN BLACK
CN201 88G 35315F HJ SOC SUBD H 15P F
CN202 88G 35424FHCJ DVI 24PIN
90G6250 1 GP HEAT SINK
Y301 93G 2251B CRYSTAL MXS12.000AC20F-
U302 56G11332PH M24C16-WBN6P
U401 56G 562117 IC NT68663MEFG-128 QFP-
U204 56G 563 25 A1C1084-33PE
U202 56G 563 31 AZ1117D-1.8-E1
U203 56G 585 4 AIC1117-33CY
U501 56G 659 7 CY7C65630-56LFXC
U402 56G1133 34 M24C02-WMN6TP
U403 56G1133 34 M24C02-WMN6TP
U502 56G1133520 IC AT25040AN-10SU-2.7 A
U201 56G4LCX 14 PH IC 74LVC14APW PHILIPS
Q403 57G 417 4 PMBS3904/PHILIPS-SMT(04
Q401 57G 417 13 T 2N3906S-RTK/PS SOT-23
Q404 57G 417 13 T 2N3906S-RTK/PS SOT-23
Q402 57G 763 1 AO3401L SOT23 BY AOS(A1
F501 61G 56075 WT6872 RST PTCR KMC 5S075R001-
F502 61G 56075 WT6872 RST PTCR KMC 5S075R001-
R212 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/
R233 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/

HP L1740 Specifications

General

3D	No
Response time	8 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Viewing angle, vertical	135 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	150 °
Digital vertical frequency	56 - 76 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1152 x 870, 1024 x 768 (XGA), 1360 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	2.0
DVI-I ports quantity	0
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (max)	60 W
Power consumption (average)	33 W
Power consumption (standby)	2 W
Power consumption (typical)	40 W
Product color	Black, White
Country of origin	China
Package weight	8800 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	248 mm
Height (with stand)	490 mm
Weight (with stand)	7000 g
Depth (without stand)	62 mm
Width (without stand)	371 mm
Height (without stand)	315 mm
Weight (without stand)	3760 g
