Setting Up the Monitor
User Guide 3–11
2. Remove the four screws 1 from the monitor base.
3. Remove the monitor base 2 from the monitor.
Removing the Monitor Base
Mounting the Monitor
1. Remove the monitor base. Refer to “Removing the Monitor
Base” steps in the previous section.
✎
For stand mounting purposes, when the base is removed, four
threaded mounting holes are exposed on the display panel. These
mounting holes are spaced 100 mm apart and are compliant with
the Video Electronics Standards Association (VESA) standard for
mounting flat panel displays.
