112 Chapter 4 - Parts and diagrams Q1342-90901
Numerical parts list
Table 28. Numerical parts list
Part Number Description Ref. Figure
7121-8042 HP jewel 7 64
Q1342-60001 Cable pod 1 63
RA0-1003-000CN Foot, rubber (paper pickup assembly) 2 69
RA0-1003-000CN Foot, rubber (plate assemblies) 10 66
RA0-1023-000CN Connecting link 7 66
RA0-1035-000CN Torsion spring 11 68
RA0-1072-000CN Grounding plate 10 68
RA0-1088-000CN Gear, 29T 5 70
RA0-1089-000CN Gear, 17T (fuser assembly) 6 70
RA0-1104-000CN Bushing 18 70
RA0-1127-000CN Engine controller case 1 67
RA0-1128-000CN PCB spacer 2 67
RA0-1161-000CN Guide, front 1 66
RA0-1169-000CN Compression spring 2 65
RA0-1172-000CN Gear 17T (drive train; left plate side) 7 65
RA0-1173-000CN Lever holder 2 66
RA0-1176-000CN Gear, 69T 6 66
RA0-1177-000CN Cover, front 1 64
RA0-1182-000CN Shutter lever 1 65
RA0-1184-000CN Cover, right support 67 65
RA0-1185-000CN Fuser plate, left 3 66
RA0-1186-000CN Fuser plate, right 4 66
RA0-1200-000CN Torsion spring 28 68
RA0-1403-000CN Cover, left side 3 64
RA0-1405-000CN Paper-pickup cover assembly 32 63
RA0-1197RA0-1197 Foot (plate assemblies) 10 67
RF0-1003-000CN Face-up roller 2 70
RF0-1008-000CN Pickup roller 8 65
RF0-1014-000CN Separation pad 24 69
RF0-1073-000CN Cover, right side 2 64
RF0-1074-000CN Top cover assembly 5 64
RG0-1003-000CN Paper-pickup assembly 68
