Q1342-90901 Numerical parts list 113
RG0-1005-000CN Feed-roller holder assembly 25 68
RG0-1006-000CN Paper lift plate assembly 22 69
RG0-1007-000CN Paper-pickup shaft assembly 23 68
RG0-1008-000CN Fuser assembly, 110 V 70
RG0-1010-000CN Face-down delivery assembly 4 70
RG0-1013-000CN Paper-pickup tray assembly 21 63
RG0-1016-000CN Back cover assembly 4 64
RG0-1020-000CN Pickup gear assembly 5 65
RG0-1026-000CN Fuser assembly, 220 V 70
RG0-1070-000CN Face-down tray assembly 5 63
RG0-1072-000CN Paper sensor PCB assembly 25A 68
RG0-1082-000CN Delivery sensor PCB assembly 26 70
RG0-1084-000CN Left plate assembly 10 65
RG0-1087-000CN Control panel assembly 11 65
RG0-1090-000CN Connector PCB assembly 12 65
RG0-1091-000CN Toner cartridge door assembly 6 64
RG0-1093-000CN Engine controller PCB assembly,
110 to127 V
467
RG0-1094-000CN Engine controller PCB assembly,
220 to 240 V
467
RG0-1097-000CN Cable, laser/scanner 4 65
RG07-1083-000CN Right plate assembly 8 66
RG9-1483-000CN Transfer roller 9 65
RG9-1498-000CN Laser/scanner assembly 3 65
RH7-1505-000CN Motor 9 66
RH7-5315-000CN Solenoid, dc 24 V 5 66
RY7-5081-000CN Clutch kit 19 68
RY7-5082-000CN Screw kit (contains a full set of screws for the
HP LaserJet 1000 and 1200 series printers)
WT2-5694-000CN Clamp, cable 3 67
Table 28. Numerical parts list (continued)
Part Number Description Ref. Figure
