HP LaserJet 1000 series - Page 45

Q1342-90910 External assemblies 33
4 Pull forward on the top of the front cover to release the three front
cover tabs (callout 2).
5 Slightly raise the front of the printer and rotate the top of the cover
toward you to release the tabs on the bottom of the front cover.
Remove the front cover.
Figure 22. Remove the front cover
12
