6 Chapter 1 Product Information C4170-90959
Product Overview
External Assembly Locations
Figure 1-2 External Assembly Locations (1 of 4)
Figure 1-3 External Assembly Locations (2 of 4)
Figure 1-4 External Assembly Locations (3 of 4)
Top output bin (face-down)
Top cover
Tray 1
Expansion trays
Tray 2
DIMM cover
Control panel
I/O cover
Rear output bin
Engine test
Power receptacle
Power switch
Toner cartridge
To Next Page
