204 Removing and replacing parts Q2431-90912
Accessories
500-sheet feeder assembly
500-sheet feed rollers
Note The removal procedure for the two paper-feed rollers located up inside of the 500-sheet feeder
is the same as the procedure for the tray 2 feed rollers. See “Tray 2 feed rollers” on page 141.
500-sheet feeder right-side cover
1. Remove two screws (callout 1) and the front cover (callout 2).
Figure 163. 500-sheet feeder right-side cover (1 of 5)
2
1
2
1
