Printer motors and fans
Figure 214. Location of printer motors and fans
1. Right-side cooling fan (HP LaserJet 4300 only)
2. Print cartridge motor (HP LaserJet 4300 only)
3. Main drive motor
4. Lifter-drive motor
5. Main cooling fan
1
2
3
4
5
