Table 8-14 Tray 1 pickup assembly
Ref Description Part number Qty
Tray 1 pickup assembly (LJ 4200/4300) RM1-0004-060CN 1
Tray 1 pickup assembly (LJ 4250/4350) RM1-1097-000CN 1
1 Tray 1 RM1-0005-020CN 1
2 Separation pad RL1-0007-000CN 1
3 Solenoid, tray 1 pickup (LJ 4200/4300) RH7-5357-000CN 1
3 Solenoid, tray 1 pickup (LJ 4250/4350) RK2-0276-000CN 1
4 Roller, pickup RL1-0019-000CN 1
Internal components 481
