Printer parts
Before using the printer, familiarize yourself with the parts of the printer.
3
4
5
1
2
6
7
1 top (face-down) output bin
2 power switch
3 optional tray 3
4 optional tray 2 (included with HP color LaserJet 2550n model)
5 tray 1
6 top cover
7 control panel
12
7
8
9
10
11
7 control panel
8 interface ports
9 optional tray 2
10 optional tray 3
11 power connector
12 rear (face-up) output door
Interface ports
The printer has two interface ports: an IEEE-1284B parallel port and a high-speed USB port.
The HP color LaserJet 2550Ln and 2550n models include an HP Jetdirect internal print
server that contains a 10/100Base-T (RJ-45) port.
ENWW Printer parts 9
