Table 4-6 Right door assembly
Ref Description Part number Qty
A Right door assembly, duplex model RM1-6104-000CN 1
A Right door assembly, simplex model RM1-6139-000CN 1
1 Roller, secondary transfer, T2 (included in the service kit) CE710-69004 1
2 Door, right upper RC2-7091-000CN 1
3 Roller, paper pickup, Tray 1 (included in the service kit) CE710-69006 1
4 Lifter plate assembly, Tray 1 RM1-6043-000CN 1
5 Separation pad, Tray 1 (included in the service kit) CE710-69006 1
6 Tray 1 (MP tray) assembly RM1-6045-000CN 1
ENWW Right door assembly 263
