Table 4-10 Internal components (4 of 6)
Ref Description Part number Qty
3 Toner collection unit (included in the service kit) CE710-69005 1
4 Arm, waste toner, left RC2-7035-000CN 1
6 Plate, arm reinforcement RC2-9649-000CN 1
7 Arm, waste toner, right RC2-7036-000CN 1
8 Spring, tension RU6-2831-000CN 1
11 Shutter, exhaust RC2-7010-000CN 1
12 Spring, compression RU6-2683-000CN 1
16 Gear, link worm RU6-0795-000CN 1
28 ITB assembly (included in the service kit) CE710-69003 1
29 Fan, power supply RK2-2276-000CN 1
32 Laser scanner assembly RM1-6122-000CN 1
33 Seal, toner supporter guide 1 RC2-7018-000CN 1
34 Toner feed assembly RM1-6040-000CN 1
37 Cable assembly, flat-flexible RM1-6804-000CN 1
ENWW Internal components (4 of 6) 271
