Numerical parts list
Table 4-21 Numerical parts list
Part number Description Table and page
CD710-69002 Fuser assembly, 220V (included in service kit) Internal components (2 of 6)
on page 267
CE490-67901 Formatter PCA (not illustrated) PCAs on page 283
CE710-69001 Fuser assembly, 110V (included in service kit) Internal components (2 of 6)
on page 267
CE710-69003 ITB assembly (included in the service kit) Internal components (4 of 6)
on page 271
CE710-69004 Roller, secondary transfer, T2 (included in the service kit) Right door assembly
on page 263
CE710-69005 Toner collection unit (included in the service kit) Internal components (4 of 6)
on page 271
CE710-69006 Roller, paper pickup, Tray 1 (included in the service kit) Right door assembly
on page 263
CE710-69006 Separation pad, Tray 1 (included in the service kit) Right door assembly
on page 263
CE710-69007 Separation roller assembly (included in service kit) Internal components (2 of 6)
on page 267
CE710-69007 Paper pickup roller assembly (included in service kit) Paper pickup assembly
on page 279
CE710-69008 Roller, pickup, paper feeder (included in service kit) Paper feeder internal
components on page 287
CE710-69008 Roller, feed, paper feeder (included in service kit) Paper feeder internal
components on page 287
RC2-6611-000CN Spring, rod Internal components (5 of 6)
on page 273
RC2-6625-000CN Cover, handle, lower-left External covers, panels, and
doors on page 261
RC2-6626-000CN Cover, handle, lower-right, rear External covers, panels, and
doors on page 261
RC2-6627-000CN Cover, handle, lower-right, front External covers, panels, and
doors on page 261
RC2-6634-000CN Rail, door link, front lower Internal components (3 of 6)
on page 269
RC2-6635-000CN Rail, door link, rear lower Internal components (3 of 6)
on page 269
RC2-6642-000CN Cover, connector, lower Internal components (2 of 6)
on page 267
RC2-6673-000CN Plate, box pillar Internal components (6 of 6)
on page 275
RC2-6691-000CN Cap, T2 contact, second-transfer high-voltage PCA Internal components (3 of 6)
on page 269
ENWW Numerical parts list 297
