Part number Description Table and page
RM1-6944-000CN Paper pickup assembly (paper feeder) Paper feeder internal
components on page 287
RM1-6946-000CN Right door assembly (paper feeder) Paper feeder external
components on page 285
RM1-6948-000CN Cover, right lower assembly (paper feeder) Paper feeder external
components on page 285
RM1-6949-000CN Cover, upper front assembly (paper feeder) Paper feeder external
components on page 285
RM1-6987-000CN Paper feeder driver PCA Paper feeder internal
components on page 287
RM1-6987-000CN Paper feeder driver PCA Paper feeder PCA
on page 289
RM1-7133-000CN Cover, front assembly External covers, panels, and
doors on page 261
RM1-7138-000CN Cassette Cassette on page 277
RM1-7142-000CN Cover, right rear External covers, panels, and
doors on page 261
RM1-7143-000CN Cover, left assembly External covers, panels, and
doors on page 261
RM1-7145-000CN Cover, right front assembly External covers, panels, and
doors on page 261
RM1-7146-000CN Cover, rear External covers, panels, and
doors on page 261
RM1-7149-000CN Cover, top External covers, panels, and
doors on page 261
RM1-7914-000CN Gear assembly, fuser Internal components (2 of 6)
on page 267
RU5-4979-000CN Shaft, right door link Internal components (3 of 6)
on page 269
RU6-0771-000CN Gear, 25T, duplex model Internal components (3 of 6)
on page 269
RU6-0772-000CN Gear, 25T, duplex model Internal components (3 of 6)
on page 269
RU6-0773-000CN Gear, 74T, duplex model Internal components (3 of 6)
on page 269
RU6-0775-000CN Gear, 18T/29T, simplex model Internal components (3 of 6)
on page 269
RU6-0795-000CN Gear, link worm Internal components (4 of 6)
on page 271
RU6-2671-000CN Spring, tension, duplex model Internal components (3 of 6)
on page 269
RU6-2683-000CN Spring, compression Internal components (4 of 6)
on page 271
Table 4-21 Numerical parts list (continued)
302 Chapter 4 Parts and diagrams ENWW
