HP LASERJET ENTERPRISE 700 COLOR MFP M775dn - Page 265

PD left cover
1. Release one tab (callout 1), and then remove the lever (callout 2).
Figure 1-321 Remove the PD left cover (1 of 3)
1
2
2. Remove one screw (callout 1), and then remove the cover.
Figure 1-322 Remove the PD left cover (2 of 3)
1
ENWW
Input devices
235
