HP LASERJET ENTERPRISE 700 COLOR MFP M775dn - Formatter PCA

Formatter PCA
CAUTION: ESD sensitive assembly.
1. Loosen two thumb screws (callout 1).
Figure 1-11 Remove the formatter PCA (1 of 2)
1
2. Pull the formatter straight out of the product to remove it.
Figure 1-12 Remove the Formatter PCA (2 of 2)
10 Chapter 1 Removal and replacement ENWW
