8. Line up the black retaining tabs in the printer with the grooves in the new pickup roller, and then
press the pickup roller into the pickup-roller seat until the retaining tabs click.
Note: Do not touch the pickup-roller pad.
Install the new separation pad. Insert as shown in picture below, then use the flatblade of your
7.
screwdriver (or your fingers) to firmly press down and lock both sides of the separation pad.
