Table 2-13 Internal assemblies (3 of 7)
Ref Description Part number Qty
1 Cassette, Tray 2 RM2-5469-000 1
2 Multi purpose clutch assembly RM1-8318-000 1
3 Pad, separation Tray 1 RL1-1785-000 1
4 Registration assembly RM1-4841-000 1
5 Paper pickup assembly RM1-8045-000 1
6 Tray 2 paper pickup roller assembly RM1-8047-000 1
7 Tray 2 separation roller assembly RM1-4840-000 1
9 Multi purpose tray assembly RM1-8610-000 1
ENWW Internal assemblies 123
