Table 2-17 Internal assemblies (7 of 7)
Ref Description Part number Qty
1 Cover, upper-rear RL1-3068-000 1
2 Cover, lower-rear RC3-1700-000 1
3 Door, rear RM1-8052-000 1
4 Reverse drive assembly RM1-4880-000 1
5
Feed guide, duplex assembly (includes transfer roller)
1
RM1-4879-000 1
6 Paper feed guide assembly (includes transfer roller) RM1-8043-000 1
7 Rib assembly, rear-door RM1-8053-000 1
9 Paper-pickup guide assembly RM1-8051-000 1
1
For a broken link-guide: you must replace either the duplexing-feed guide assembly, or the entire product (the interior paper guide is
not replaceable).
ENWW Internal assemblies 131
